Thursday 12 August 2010

Configuring the People Picker and No exact match was found

SharePoint's people picker is generally one of those things that just kind of works—and fairly well no less. There's a gotcha to that statement however: the people picker works well when the the SharePoint farm exists in the same domain as the users you want to match against, or exists in a second domain where a two-way trust has been established with the first domain.

SharePoint-People-Picker

If your SharePoint web frontends exist in another domain with a one-way trust, you've got some extra work to do. This is the case with our dev setup and DMZ setup: our dev VMs are joined to the dev domain which trusts the corporate domain and our production servers are similarly joined to a web domain that also trusts the corporate domain. Both trusts are one-way.

I'll simplify what needs to be done by stating you simply need to tell SharePoint which forests or domains house the users you're after and provide an account from that domain.

Firstly you'll need to provide a key that will be used to encrypt any passwords you plug in during the next step. Run this on every WFE where "key" is a string of your choosing:

STSADM.exe -o setapppassword -password key

Next, set the peoplepicker-searchadforests property:

STSADM.exe -o setproperty-propertyname peoplepicker-searchadforests -propertyvalue <Valid list of forests or domains> -url <URL of the Web application>

where <Valid list of forests or domains> might look like this:

"domain:mydomain.com,mydomain\myuser,mypassword"

Supply the URL of the web application you want to configure (and note you don't need to set this for Central Admin, set it for a specific web application). Multiple domains and forests can be listed if necessary.

For more information, check out these resources:


If you found this post helpful, please support my advertisers:

1 comment:

  1. I think there are some limitations of share-point people picker as, it restrictive the people picker search to within an Active Directory Organizational Unit and it disable the returning windows accounts when the authentication method for the web application is using forms based authentication. Can we fix these limitations? And I have another question that is it possible to use one people-picker filed and on name selection, populate other text box?
